2023 Ducati Multistrada V4

2023 Ducati Multistrada V4 Pikes Peak Livery

Rule all mountains

When sportiness is more important to you than anything else.

The Multistrada V4 Pikes Peak was developed to bring the sporty qualities of the Multistrada V4 S to the extreme: a dedicated riding position, 17" wheels with sports tyres, single-sided swingarm, Öhlins suspension and the new Race Riding Mode.

A bike that is sharp, precise and effective even on the track.

The Multistrada V4 Pikes Peak is not only the sportiest Multistrada ever, it is also the most powerful model in the entire crossover segment.

Exciting and adrenalin-fuelled, it is powered by the V4 Granturismo engine, capable of delivering 170 hp at 10,500 rpm and guaranteeing high performance in sporty riding thanks to new electronic management strategies.

Features may include:

• RACING STYLE

The 17” front wheel makes the riding responsive and sharp. Rims are forged aluminum and results in a weight reduction that enhances the dynamic behaviour of the vehicle.

• CHASSIS

The V4 Pikes Peak is the first Multistrada in history to be equipped with Öhlins electronic suspension tuned to the rider's riding style

• ERGONOMICS

A dedicated riding position has been designed for the Multistrada V4 Pikes Peak to ensure a sporty and effective riding position

• ENGINE

The V4 Pikes Peak features the V4 Granturismo with updates to the electronic management system focused on improved performance on the road and track

• ELECTRONICS

For the first time a Multistrada features a Race riding mode. Other electronic sport-oriented updates are related to wheelie control, quickshifter and ABS calibration.

• DESIGN

New "Pikes Peak" livery is inspired by the colors and graphics of the Desmosedici GP '21. To emphasise its sporty-oriented attitude it comes with a wide range of components made of carbon fiber and a low dark-smoked windshield

Engine

• Engine TypeV4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, Twin Pulse firing order
• Bore83 mm
• Stroke53.5 mm
• Displacement1,158 cc (71 cu in)
• Engine Power170 hp (125 kW) @ 10,500 rpm
• Engine Torque12.7 kgm (125 Nm, 92 lb ft) @ 8,750 rpm
• Compression Ratio14.0:1
• EmissionsBike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
• CoolingLiquid Cooled

Fuel System

• Fuel InjectionElectronic fuel injection system, Øeq 46 mm elliptical throttle bodies with Ride-by-Wire system

Drivetrain

• ClutchMultiplate wet clutch with hydraulic control, self-servo action on drive, slipper action on over-run
• Gearbox6 speed with Ducati Quick Shift (DQS) up/down
• Final DriveChain, front sprocket z16, rear sprocket z42
• Gear Ratios (overall) 1st40/13
• Gear Ratios (overall) 2nd36/16
• Gear Ratios (overall) 3rd34/19
• Gear Ratios (overall) 4th31/21
• Gear Ratios (overall) 5th29/23
• Gear Ratios (overall) 6th27/25
• Primary DriveStraight cut gears, ratio 1.8:1

Chassis

• Frame TypeAluminium monocoque frame
• ExhaustStainless steel muffler, double catalytic converter and 4 lambda probes

Suspension

• Front SuspensionÖhlins Ø 48 mm fully adjustable usd fork with TiN treatment, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode
• Rear SuspensionÖhlins TTX36 fully adjustable monoshock, electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode, electronic preload adjustment, aluminium single-sided swingarm

Brakes

• Front braking system2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston 2-pad calipers, radial master cylinder, Cornering ABS
• Rear braking systemØ 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS

Wheels & Tires

• Front WheelMarchesini light alloy forged, 3.5
• Rear WheelMarchesini light alloy forged, 6
• Front TirePirelli Diablo Rosso IV 120/70 ZR17
• Rear TirePirelli Diablo Rosso IV 190/55 ZR17
• Front Wheel Travel170 mm (6.7 in)
• Rear Wheel Travel170 mm (6.7 in)

Dimensions

• Wheelbase1,595 mm (62.8 in)
• Seat HeightAdjustable: 840 mm - 860 mm (33.1 in - 33.9 in) | with high seat accessory: 855 mm - 875 mm (33.7 in - 34.4 in) | with low seat accessory: 810 mm - 830 mm (31.9 in - 32.7 in)
• Rake/trail25,75° / 120 mm (4.7 in)

Capacities

• Fuel Capacity22 l (5.8 US gal)
• Seating Capacity2

Weights

• Curb Weight239 kg (527 lb)
• Dry Weight214 kg (472 lb)

Features

• FeaturesStandard equipment: Öhlins Smart EC 2.0 electronic suspension, Ducati Quick Shift, Adaptive Cruise Control, Hands-free, Backlit handlebar switches, 6.5
• Instrumentation6.5
• Safety FeaturesRiding Modes, Power Modes, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Vehicle Hold Control, Blind Spot Detection

Warranty

• Warranty24 months, unlimited mileage.
