2024 Ducati Diavel V4

Engine

• Bore / stroke83 mm x 53.5 mm
• Compression ratio14.0:1
• Displacement1,158 cc (71 cu in)
• TypeV4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, Twin Pulse firing order, liquid cooled
• ExhaustStainless steel exhaust muffler with 4 exit pipes, 2 catalytic converters and 4 lambda probes
• Fuel injectionElectronic fuel injection system, Øeq 46 mm elliptical throttle bodies with Ride-by-Wire system
• Power168 hp (124 kW) @ 10,750 rpm
• Torque93 lb ft (126 Nm, 12.8 kgm) @ 7,500 rpm

Power transmission

• ClutchHydraulically controlled slipper and self-servo wet multiplate clutch
• Gearbox6 speed with Ducati Quick Shift up/down
• Final driveChain, front sprocket z16, rear sprocket z43
• Primary driveStraight cut gears; Ratio 1.80:1
• Ratio1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25

Dimensions / weights

• Seat height31.1 in (790 mm)
• Fuel tank capacity5.3 US gal (20 l)
• Number of Seats2
• Rake26°
• Trail4.4 in (112 mm)
• Wet weight no fuel223 lb (492 kg)

Chassis / brakes

• FrameAluminum monocoque frame
• Front Brake2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston calipers, radial master cylinder PR16/19, Cornering ABS
• Front suspensionØ 50 mm fully adjustable usd fork
• Front TirePirelli Diablo Rosso III, 120/70 ZR17
• Front WheelLight alloy cast, 3,5
• Instrumentation5
• Rear BrakeØ 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
• Rear suspensionFully adjustable monoshock, aluminum single-sided swingarm
• Rear TirePirelli Diablo Rosso III, 240/45 ZR17
• Rear WheelLight alloy cast, 8,0
• Wheel Travel (Front/Rear)4.7 in / 5.7 in (120 mm/145 mm)

Mileage / consumption

• Notes*Please check with your dealer product availability Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information

Equipment

• Ready forTurn-by-Turn navigation system
• Safety EquipmentRiding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light*, Ducati Brake Light
• Standard equipmentDucati Quick Shift, Ducati Power Launch, Cruise control, Hands-Free, 5

Warranty

• Maintenance9,000 miles (15,000 km) / 24 months
• Valve Clearance Check37,000 miles (60,000 km)
• Warranty24 months, unlimited mileage
